MG B-Seam panel systems are formed to suit a wide variety of substrates and applications perfect for roofs and walls. This style of standing seam panels feature a snap on batten cap and are mechanically fastened with concealed fasteners. The hold down clips and batten caps allow for movement while still providing a unique design. Panels are installed in a sequential pattern, overlapped and sealed as required to form a watertight system
MG B-SEAM
STANDING SEAM STYLE PANEL SYSTEM
PANEL COMPOSITION
MATERIAL OPTIONS & FINISHES
| MATERIAL | THICKNESS | FINISHES |
| Steel | 20 – 26 gauge | MG steel custom patina finishes, or standard and custom colors |
| Stainless | 24 – 26 gauge | Standard and custom colors available |
| Aluminum | .032” & .40” | Standard and custom colors available |
| Copper | 16oz, 20oz, & 24oz | MG copper custom patina finishes |
| Zinc | .7mm & .8mm | MG zinc custom patina finishes, or standard and custom colors |
*Material, sizes, and spacings are rough estimates. Capabilities and options vary as material gauge and panel length fluctuate. Please contact us for a more detailed range of capabilities as engineering allows*
TECHNICAL DATA & SPECIFICATIONS
FEATURES & OPTIONS
Features & Options
-
Includes hold-down clips, batten caps, and stiffeners if required
-
Panel system to accommodate substructure tolerance of +0 to -1/8 inch
-
Panels can be installed over almost any substrate
-
Custom alloys available based on material choice
