By HGA Architects and Engineers
Created in collaboration with Christian M Korab, Marc Ofsthun, Pete Sieger, Tom Dolan, and Rob McIntosh
MG McGrath Scope of Work:
Exterior: MG McGrath installed 3″ inch Thermax sheathing, Z furring, 3/4 inch plywood, 30# felt, copper vertical standing seam wall panels out of 16 ounce copper. MG McGrath fabricated all of the window trims using .063 inch polished, and patinized Muntz Bronze. Conical skylights were installed on the green roof and they were made of 1/8” polished, and patinized Muntz Bronze. All exterior copings consisting of Quartz Zinc, and 1/8 inch Bronze were fabricated by MG McGrath.
Interior: Interior oculus skylight trim rings were fabricated and installed by MG McGrath. They were then plastered over to give the entire interior of the skylight the same finish. MG McGrath fabricated face plates to modify exit light signs using 1/8 inch Aluminum which received a plaster finish to blend in with the wall, and the Bronze, which was installed into an architectural brick wall. MG McGrath fabricated slotted, radiused, .090 inch diffusers directly inside the glass of the conical skylights and they can be seen from outside on the green roof. We fabricated 3 round, conical, cover plates for the Bocci lights on the second floor of the mausoleum. They were fabricated and installed in a manner that allows a person to change a light bulb without taking the entire cover plate off. They are mounted with fasteners, but also have a chain which will hold the cover from falling when the fasteners are removed. All of the interior window frames were clad with .063 inch patinized Muntz Bronze.
